Inside wall constructions

Partition wall

1 GKB plasterboard 12,5mm

2 Calibrated timber 45x95mm, cc=600mm (studs) C24

3 Stone wool insulation Paroc Ultra 75mm

4 GKB plasterboard 12,5mm

Load-bearing wall

1 GKB plasterboard 12,5mm

2 Kalibruota mediena C24 45x95mm, cc=600mm

3 Stone wool insulation Paroc Ultra 100mm

4 GKB plasterboard 12,5mm

Fireproof wall EI60

1 GKF plasterboard (red) 12,5mm

2 GKF plasterboard (red) 12,5mm

3 Calibrated timber 45x95mm, cc=600mm (studs) C24

4 Stone wool insulation Paroc Ultra 100mm

5 Air gap 30mm + steelwire

6 Calibrated timber 45x95mm, cc=600mm (studs) C24

7 Stone wool insulation Paroc Ultra 100mm

8 GKF plasterboard (red) 12,5mm

9 GKF plasterboard (red) 12,5mm
